Install and Config Fail2Ban in Debian 7 Wheezy

Fail2Ban (authentication failure monitor) is an intrusion prevention software, written in Python. Fail2Ban analyzes various services log files (ssh, apache, postfix etc) and if it detects possible attacks (mainly Brute-force attacks), it creates rules on the firewall (iptables and many others) or tcp wrappers (/etc/ hosts.deny) to ban (temporarily or permanently) the wannabe hacker. Simultaneously, fail2Ban informs system administrator with email for its activity in real time.

Some activities which considered as attacks are:

multiple attempts for ssh connection using accounts that do not exist in the system
multiple attempts for ssh connection switching passwords
Apache requests for web pages often requested by bots and scanners.

You do not need fail2ban (not even iptables) if your hosting provider offers a dedicated hardware firewall. Of course, you must have the budget to pay for it and the knowledge to setup and manage it.

Hardware firewalls as Cisco ASA 550 series and even smaller devices as FortiGate-60C can offer protection, which fail2ban offers (and moreover).

Setup

Using apt-get, fail2ban 0.8.6-3wheezy1 will be installed:

apt-get install fail2ban

After installation the following files have been created:

/etc/fail2ban/fail2ban.conf (basic settings)
/etc/fail2ban/jail.conf (settings for various services monitoring). Only ssh monitoring through iptables has been activated by default)
directory /etc/fail2ban/action.d/ actions to ban suspected IP
directory /etc/fail2ban/filter.d/ filters (regular expressions) through which fail2ban detects malicious attacks in log files

Also, log rotation settings for fail2ban has been created by Debian.

Configuration

Do not use /etc/fail2ban/jail.conf, create /etc/fail2ban/jail.local instead:

nano /etc/fail2ban/jail.local

In summary:

ignoreip: localhost (127.0.0.1) and server management IPs or any other trusted IP
bantime: 86400 one day (in seconds), the time after which ban will be removed (actionunban). Negative values (eg bantime = -1) make the ban permanent, but this is not particularly useful, as the bots will “seek” another server after the ban.
banaction: the preferred option to ban the suspected IP address
- using “iptables-multiport” (recommended), iptables firewall will be used to ban the suspected IP
  After system or fail2ban restart, all ban firewall rules will be cleared.
- using “hostsdeny” tcp-wrappers (/etc/hosts.deny) will be used for ban
action: %(action_mwl)s (it means: ban and send an e-mail with whois report and relevant log lines)

So, my settings are:

REMARK: Remember to replace you@your-email.com with your email. destemail = you@your-email.com is not needed if you have forwarded root mail.

[DEFAULT]
ignoreip  = 127.0.0.1 82.192.71.9 95.211.46.207
bantime   = 86400
destemail = you@your-email.com
banaction = iptables-multiport
action    = %(action_mwl)s

# JAILS
[ssh]
enabled   = true
maxretry  = 3

[pam-generic]
enabled   = true
banaction = iptables-allports

[ssh-ddos]
enabled   = true

[webmin]
enabled   = true
port      = 10000,20000
filter    = webmin-auth
banaction = iptables-multiport
action    = %(action_mwl)s
logpath   = /var/log/auth.log
maxretry  = 3

[apache]
enabled = true

[apache-noscript]
enabled   = true
port      = http,https
banaction = iptables-multiport
action    = %(action_mwl)s

[apache-overflows]
enabled   = true

[apache-badbots]
enabled   = true
port      = http,https
filter    = apache-badbots
banaction = iptables-allports
action    = %(action_mwl)s
logpath   = /var/log/apache*/*access.log
maxretry  = 1

[apache-nohome]
enabled   = true
port      = http,https
filter    = apache-nohome
banaction = iptables-multiport
action    = %(action_mwl)s
logpath   = /var/log/apache*/*access.log
maxretry  = 1

[php-url-fopen]
enabled   = true
port      = http,https
filter    = php-url-fopen
logpath   = /var/log/apache*/*access.log
maxretry  = 1

[exim]
enabled  = true
filter   = exim
port     = smtp,ssmtp
logpath  = /var/log/exim*/rejectlog
maxretry = 1

[apache-w00tw00t]
enabled   = true
port      = http,https
filter    = apache-w00tw00t
banaction = iptables-allports
action    = %(action_mwl)s
logpath   = /var/log/apache*/*error.log
maxretry  = 1

[apache-myadmin]
enabled   = true
port      = http,https
filter    = apache-myadmin
banaction = iptables-allports
action    = %(action_mwl)s
logpath   = /var/log/apache*/*error.log
maxretry  = 2

apache-w00tw00t is a custom filter (details here). So, first create:

nano /etc/fail2ban/filter.d/apache-w00tw00t.conf

as follows

[Definition]

# Option:  failregex
# Notes.:  regex to match the w00tw00t scan messages in the logfile.
# Values:  TEXT
failregex = ^.*[client <HOST>].*w00tw00t.at.ISC.SANS.DFind.*

                # Option: ignoreregex
                # Notes.: regex to ignore. If this regex matches, the line is ignored.
                # Values: TEXT
                ignoreregex =

apache-myadmin is a custom filter (details here). So, first create:

nano /etc/fail2ban/filter.d/apache-myadmin.conf

as follows

[Definition]
failregex = ^[[]client <HOST>[]] File does not exist: *myadmin* *s*$
                ^[[]client <HOST>[]] File does not exist: *MyAdmin* *s*$
                ^[[]client <HOST>[]] File does not exist: *mysqlmanager* *s*$
                ^[[]client <HOST>[]] File does not exist: *setup.php* *s*$
                ^[[]client <HOST>[]] File does not exist: *mysql* *s*$
                ^[[]client <HOST>[]] File does not exist: *phpmanager* *s*$
                ^[[]client <HOST>[]] File does not exist: *phpadmin* *s*$
                ^[[]client <HOST>[]] File does not exist: *sqlmanager* *s*$
                ^[[]client <HOST>[]] File does not exist: *sqlweb* *s*$
                ^[[]client <HOST>[]] File does not exist: *webdb* *s*
ignoreregex =

Start or restart fail2ban

systemctl start fail2ban.service

Other settings

Restart after system crash

Fail2ban will probably not start after system crash or power loss. In this case:

rm /var/run/fail2ban/fail2ban.sock
systemctl restart fail2ban.service

Notification mail settings

Just edit the relevant file

nano /etc/fail2ban/action.d/sendmail-whois-lines.conf

Complex iptables structure

In systems with very complex iptables structure problems may occur during fail2ban chains creation. There is a workaround:

nano /usr/bin/fail2ban-client

Add time.sleep(0.1) (line 145)

        def __processCmd(self, cmd, showRet = True):
                        beautifier = Beautifier()
                        for c in cmd:
                                        time.sleep(0.1)
                                        beautifier.setInputCmd(c)

Useful commands

To check fail2ban activity:

Logs: tail /var/log/fail2ban.log
Check status: fail2ban-client status
Check status of certain service: fail2ban-client status ssh
Check regex results: fail2ban-regex /var/log/auth.log /etc/fail2ban/filter.d/sshd.conf

Unblock IP

If unblock an IP is needed:

using iptables: iptables -D fail2ban-<CHAIN_NAME> -s <IP> -j DROP
using tcp-wrappers: remove IP from /etc/hosts.deny

Restrictions

There are some restrictions:

Fail2ban does not protect from distributed brute force attacks.
Fail2ban does not yet support ipv6.

Other services

Fail2Ban can monitor many other services. Here are some examples:

postfix

nano /etc/fail2ban/jail.local

add the following

[postfix]
enabled  = true
maxretry = 1

mod-security

Create the custom filter

nano /etc/fail2ban/filter.d/apache-modsec.conf

as follows

# Fail2Ban configuration file
#
# Author: Florian Roth

[Definition]
failregex = [.*?]s[w-]*s<HOST>s
ignoreregex =

then

nano /etc/fail2ban/jail.local

add the following (you can modify it to fit your needs)

[apache-modsec]
enabled   = true
port      = http,https
filter    = apache-modsec
banaction = iptables-multiport
action    = %(action_mwl)s
logpath   = /var/log/modsecurity/audit.log
maxretry  = 1

mod-evasive

Create the custom filter

nano /etc/fail2ban/filter.d/apache-modevasive.conf

as follows

# Fail2Ban configuration file
#
# Author: Xela
#
# $Revision: 728 $
#

[Definition]

# Option:  failregex
# Notes.:  regex to match the Forbidden log entrys in apache error.log
#          maybe (but not only) provided by mod_evasive
#
# Values:  TEXT
#
failregex = ^[[^]]*]s+[error]s+[client <HOST>] client denied by server configuration:s

                # Option:  ignoreregex
                # Notes.:  regex to ignore. If this regex matches, the line is ignored.
                # Values:  TEXT
                #
                ignoreregex =

then

nano /etc/fail2ban/jail.local

add the following (you can modify it to fit your needs)

[apache-modevasive]
enabled   = true
port      = http,https
filter    = apache-modevasive
banaction = iptables-allports
action    = %(action_mwl)s
logpath   = /var/log/apache*/*error.log
bantime   = 600
maxretry  = 3

DDOS protection

Useful approaches to DDOS protection:

Examples

Fail2Ban sample reports:

fail2ban_sample_report_ssh Download

fail2ban_sample_report_postfix Download

fail2ban_sample_report_pam-generic Download

fail2ban_sample_report_apache-overflows Download

fail2ban_sample_report_mod_security Download

fail2ban_sample_report_mod_evasive Download

fail2ban_sample_report_apache-w00tw00t Download

fail2ban_sample_report_ssh-ddos Download

fail2ban_sample_report_apache-badbots Download

fail2ban_sample_report_apache-noscript Download

fail2ban_sample_report_php-url-fopen Download
